LIMBOPLAST D480 plain / structure / profile
Cold Plastic
LIMBOPLAST D480 belongs to the group of solvent-free, multi-component, reactive systems and consists of two or more components which – through chemical interaction – form a duroplastic compound that cannot be thermally plastified any more.
LIMBOPLAST D480 has been tested and approved by several test reports on the turntable simulator at the German Road Institute (BASt) as TYPE I and TYPE II (rain safety marking) marking:
- Plain: LIMBOPLAST D480 plain can be applied as conventional marking and as rain safety marking with enhanced wet night visibility.
- Structure: LIMBOPLAST D480 is exclusively applied as agglomerate-type rain safety marking with enhanced wet night visibility. It is characterized by an open structure (agglomerates) with excellent drain effect and good resistance against snowploughs.
- Profile: It has been tested and approved on the turntable simulator at the German Road Institute (BASt) as type II marking.
RPA - Test Reports by BASt for LIMBOPLAST D480 plain / structure / profile
Test report-no. | Layer thickness | Consumption | Drop-on material (DOM) | Traffic technological properties | ||
mm | Material | DOM | Identification (divergent identification possible - see relevant test report) | New condition | Used condition | |
kg/m² | kg/m² | |||||
Structure Markings / Regular Agglomerates | ||||||
1.5-3.0 | 2.3-2.8 | 0.50 | SWARCO SOLIDPLUS 10 100-600 T18 | P7, S0, R5, RW6, Q5, T3 | P7, S0, R5, RW6, Q5 | |
1.5-3.0 | 2.4-2.8 | 0.45 | SWARCO SOLIDPLUS 50 100-800 T18 | P7, S0, R5, RW6, Q5, T3 | P7, S0, R5, RW5, Q4 | |
1.5-3.0 | 2.3-2.8 | 0.50 | SWARCO SOLIDPLUS 10 P21 T18 | P7, S0, R5, RW6, Q5, T3 | P7, S0, R5, RW6, Q5 | |
1.5-3.0 | 2.3-2.8 | 0.50 | SWARCOLUX P21 T18 | P7, S0, R5, RW6, Q5, T3 | P7, S0, R5, RW5, Q5 | |
1.5-3.0 | 2.4-2.8 | 0.50 | SWARCOFLEX 100-600 T18 | P7, S0, R5, RW6, Q5, T3 | P7, S0, R5, RW5, Q5 | |
Structure markings / Irregular Agglomerates | ||||||
1.5-3.0 | 2.2-2.8 | 0.40 | SWARCOLUX P21 T18 | P7, S0, R5, RW6, Q5, T3 | P7, S0, R5, RW6, Q5 | |
1.5-3.0 | 2.2-2.8 | 0.50 | SWARCO SOLIDPLUS 10 100-600 T18 | P7, S0, R5, RW6, Q5, T3 | P7, S0, R5, RW5, Q5 | |
1.5-3.0 | 2.2-2.8 | 0.49 | SWARCO SOLIDPLUS 10 P21 T18 | P7, S0, R5, RW5, Q5, T3 | P7, S0, R5, RW5, Q5 | |
1.5-3.0 | 2.5-2.8 | 0.50 | SWARCOFLEX 100-600 T18 | P7, S0, R5, RW6, Q5, T3 | P7, S0, R4, RW4, Q5 | |
1.5-3.0 | 2.5-2.8 | 0.50 | SWARCO SOLIDPLUS 50 212-850 T18 | P7, S0, R5, RW6, Q5, T3 | P7, S0, R5, RW5, Q5 | |
1.5-3.0 | 2.5-2.8 | 0.50 | SWARCOLUX P21 T18 | P7, S0, R5, RW6, Q5, T3 | P7, S0, R5, RW5, Q5 | |
1.5-3.0 | 2.3-2.8 | 0.50 | SWARCO SOLIDPLUS 10 P21 T18 | P7, S0, R5, RW6, Q5, T3 | P7, S0, R5, RW4, Q5 | |
1.5-3.0 | 2.3-2.8 | 0.50 | SWARCO SOLIDPLUS 100 300-850 T18 | P7, S0, R5, RW6, Q5, T3 | P7, S0, R5, RW4, Q5 | |
2021 1VK 10.06 | 1.5-3.0 | 2.6-2.8 | 0.50 | SWARCOLUX P21 T18 | P7* | |
2022 1VK 07.17 | 1.5-3.0 | 2.7-2.8 | 0.50 | SWARCOLUX P21 T18 | P7* | |
Plain markings | ||||||
Type I markings | ||||||
2.0 | 3.68 | 0.40 | SWARCOLUX P21 T18 M25 | P7, S1, R5, Q5, T3 | P7, S1, R5, Q5 | |
3.0 | 5.52 | 0.45 | SWARCOLUX P21 T18 M25 | P7, S1, R4, Q5, T3 | P7, S2, R4, Q5 | |
Type II markings | ||||||
2.0 | 3.68 | 0.40 | SWARCOLUX 50 425-1400 T18 MK30 | P7, S1, R5, RW6, Q5, T3 | P7, S1, R5, RW4, Q5 | |
2.0 | 3.68 | 0.45 | SWARCO SOLIDPLUS 10 425-1400 T18 MK30 | P7, S1, R5, RW4, Q5, T3 | P7, S1, R5, RW3, Q5 | |
3.0 | 5.52 | 0.40 | SWARCOLUX 50 425-1400 T18 MK30 | P7, S1, R5, RW6, Q5, T3 | P7, S1, R5, RW4, Q5 | |
3.0 | 5.52 | 0.45 | SWARCO SOLIDPLUS 10 425-1400 T18 MK30 | P7, S1, R5, RW4, Q5, T3 | P7, S1, R5, RW3, Q5 | |
3.0 | 5.52 | 0.40 | MEGALUX-Beads 600-1400 T18 MK30 | P7, S1, R4, RW5, Q5, T3 | P7, S1, R5, RW5, Q5 | |
Profile markings | ||||||
| Type II markings | ||||||
2/5 | approx. 5-6 | 0.40 | SWARCOLUX P21 T18 M25 | P7, S1, R5, RW5, Q5, T4 | P7, S0, R4, RW5, Q5 | |
3/9 | approx. 5-6 | 0.50 | SWARCO SOLIDPLUS 10 P21 T18 | P7* | P7* | |
Irregular agglomerates for renovation | ||||||
1.6 | 0.50 | SWARCO SOLIDPLUS 10 P21 T18 | P7* | P7* | ||
1.6 | 0.50 | SWARCO SOLIDPLUS 50 P21 T18 | P7* | P7* | ||
*only confirmation of testing the marking systems available
